FOCUS 200 PLUS Installation and Setup Guide
14-4
< ? FRONT DOOR 20
Type MD Continue >
Type – 0 3
< Previous Enter >
Select
Enter
to save this info and then select
Continue
to move to
the next screen
.
< ? FRONT DOOR 20
Group 1 Continue >
PERIMETER
< Previous Enter >
Group Assignment Screen
is displayed
.
The default group assignment is Group 1. Enter the number of the
group to which this point should be assigned.
Select
Enter
to save this info and then select
Continue
to move to
the next screen
.
< ? FRONT DOOR 20
Link _ _ _ Continue >
< Previous Enter >
Point Link Screen
is displayed
.
If this point is not to be linked to another point, select
Continue
.
If this point is to be linked with another point, enter the point
number. If that point has been fully programmed, the name will
appear on the third line.
Select
Enter
and then
Continue
to save this info and move to the
next screen.
< ? FRONT DOOR 20
IS _____ Continue >
BYPASSABLE
< Previous Change >
Bypass Screen
is displayed.
Selecting
Change
will toggle the bypass option between “IS NOT
BYPASSABLE” and “IS BYPASSABLE.”
Select
Continue
to save the info and move to the next screen.
< ? FRONT DOOR 20
IS _____ Continue >
OPTION 1
< Previous Change >
This is
Option 1 Screen
.
The function of Option 1 changes depending on the type of point
being used.
For Input Point Types 2, 3, 5 to 8 = Janitor Point:
This point is automatically bypassed during the Nite Set if a
Janitor Keyswitch is used.
For Input Point Types 10, 11 = Suspicion Point:
A separate normally closed device causing an open triggers a
Holdup Suspicion output. If the open is held for more than 1
minute, a trouble occurs.
For Input Point Type 60 = Log Event:
Select whether an occurrence will be logged in the system’s history.
For Output Point Types 14 to 26, 33, 34, 37, 59 = Complement
Point:
Select this option to reverse the function of the output. An output
that normally is turned on when the system detects a condition will
be turned off.
For Output Point Type 27 = Strobe:
Select whether a strobe is used instead of a bell. The strobe will
flash continuously for an alarm.
For Output Point Type 38 = Inhibit BA:
Select whether the output is inhibited for BAs.
Selecting
Change
will toggle the option.
Select
Continue
to save the selection and move to the next option
screen.
