5702269-C I/O Communication and Control 4-61
Pinnacle™ Plus+ 10 kW
6
set point
Specifies the output set point level for
whichever method of regulation mode has been
selected.
Send 2 data bytes (16-bit value); an output
power value implies 3 decimal places for a
stand-alone unit and 2 decimals for a master/
slave unit. An output current value should
imply 2 decimal places, and an output voltage
value should imply 0 decimal places. For
example, for a 6 kW, standard Z stand-alone
supply, send a value between 0 and 6000
(6.000 kW, decimal is implied), or 0 and 1500
(15.00 A, decimal is implied), or 0 and 800
(maximum output voltage).
Please refer to the “Specifications” chapter of
this manual for your unit's capabilities.
Note: If the ramp feature is enabled
(commands 15 and 16), sending this
command while the output is on will
force the unit to ramp from the existing
set point to the new requested set point
over the time specified in command 16.
Thus, by using this command and
commands 15 and 16, you can generate
an output wave form during a process.
Read back this value with command 164.
2 CSR Codes:
0,1,4,6,9
19
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
