4-62 I/O Communication and Control 5702269-C
Advanced Energy
®
8
arc shutdown
time
Send 2 data bytes to set the arc shutdown time.
• Byte 1 = Unused
• Byte 2 = Send the appropriate value below
indicating the arc shutdown time (in µs).
4
0 = 200
4
1 = 500
4
2 = 1000
4
3 = 1500
4
4 = 2000
4
5 = 2500
4
6 = 3000
4
7 = 4000
4
8 = 5000
Readback this value with command 170.
2 CSR only
9
hard arc
count limit
Sets the number of hard arcs required for the
power supply to provide an arc indication. (If
the limit is reached during a process cycle, then
after output shuts off, the ARC LED on the
passive panel or active control panel lights and,
if applicable, a pulse is sent to the User port
ARC.D output signal. For more information,
see “I/O Communication and Control” on
page -1 .
Send 4 data bytes (a 32-bit value) indicating
the number of arcs; the value must be at least 0
but no greater than the maximum set for your
unit.
Note: If you set the hard arc count limit to 0,
each time a hard arc occurs the ARC
LED lights for a predetermined time
and, if applicable, a signal is sent to the
User port.
Read back this value with command 178.
4 CSR codes:
0,1,4,9
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
To Next Page
