4-64 I/O Communication and Control 5702269-C
Advanced Energy
®
11
active target
Specifies which target will be active.
Send 1 data byte (8-bit value); the value must
be at least 1 but no greater than 8.
Note: The User port has priority for target
selection. Thus to select targets from the
active front panel or from the Pinnacle
Remote Panel (that is, when the Pinnacle
Plus+ unit is in local or host control
mode), you must set the target to 1 at the
User port. Leaving the target bits open or
leaving the User port pins unconnected
causes the target selection at the User
port to default to 1.
Read back this value with command 156.
1 CSR codes:
0,1,2,4,9,10
12
target life
Sets the life (in kilowatt-hours) of the target
you specify.
Send 1 data byte (8-bit value) plus 4 data bytes
(32-bit value), arranged as follows:
• First byte = Target number
• Second/third/fourth/fifth bytes = Target
life (in kilowatt-hours); two decimal
places are implied (that is, to get 1 kW,
send a value of 100).
Read back this value with command 157.
5 CSR codes:
0,1,2,4,9
13
target enable
Enables or disables the target life counter.
Send 1 data byte (8-bit value):
• 0 = Inactive
• Non-zero value = Target life is active
Read back this value with command 163.
1 CSR codes:
0,1,2,9
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
