5702269-C I/O Communication and Control 4-65
Pinnacle™ Plus+ 10 kW
14
control mode
Chooses the mode of control for the Pinnacle
Plus+ supply.
Send 1 data byte:
• 2 = Serial (Host) port
•4 = User port
• 6 = Active control panel
Read back this value with command 155.
1 CSR codes:
0,2,5,9,12
15
ramp enable
Enables or disables the ramp feature.
Send 1 data byte (8-bit value):
•0 = Disable
• Non-zero = Enable
Read back this value with command 163.
1 CSR codes:
0,1,2,9,19
16
ramp time
Sets the ramp time in 10 ms increments. Range
is 50 ms to 600.00 s.
Send a 2-byte value between 5 and 60,000.
Two decimal places are implied. (To get 1 s,
send a value of 100.)
Note: If your unit has 100 ms ramp feature
enabled, one decimal is implied. The
range is 0.5 s to 6000.0 s.
Read back this value with command 158.
2 CSR codes:
0,1,4,9
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
