5702269-C I/O Communication and Control 4-69
Pinnacle™ Plus+ 10 kW
24
calculate
logic CRC
Tells the Pinnacle Plus+ supply to calculate its
logic CRC.
Note: During the approximately 2 seconds it
takes to calculate the CRC, the Pinnacle
Plus+ unit will not respond to any other
commands.
Read this value back with command 230.
0 CSR codes:
0,2,9
26
joule
threshold
Specifies the output level that needs to be met
before the Joule output energy calculation
begins (the joule threshold). The joule
threshold type (power, voltage, or current) is
set with command 64.
If the threshold type is set in Watts, send 2
bytes (16-bit value) between 10 and maximum
power divided by 8. This value represents watts
in a stand-alone system and decawatts in a
master/slave system.
For threshold types set in Volts or Amps, send
2 bytes (16-bit value) between 0 and the
maximum output limit.
Note: The Joule energy calculation begins after
(n) mS, regardless of the output level.
The time value, (n) mS, is set in the
configuration and cannot be changed. If
the output level meets the joule energy
threshold prior to the time expiration, the
joule energy calculation will begin.
Read back this value with command 136.
2 0, 1, 2, 4, 9
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
