5702269-C I/O Communication and Control 4-81
Pinnacle™ Plus+ 10 kW
155
request
control mode
Requests control mode; the returning packet
contains 1 data byte (8-bit value):
• 2 = Serial (Host) port
• 3 = Active control panel (Local)
•4 = User port
This value is set with command 14.
01
156
request
active target
number
Requests an indication of the active target; the
returning packet contains 1 data byte indicating
target 1, 2, 3, 4, 5, 6, 7, or 8.
This value is set with command 11.
01
157
request target
life
Requests the amount of target life time
remaining for the target you specify.
Send 1 data byte indicating which target; the
returning packet contains 4 data bytes (32-bit
value) indicating the time remaining in
kilowatt-hours. Two decimal places are
implied. For example, a value of 100 indicates
1 kWh.
This value is set with command 12.
14
(May return
CSR code 4)
158
request ramp
time
Requests ramp time. Returns a 2-byte value (16
bits) indicating a ramp time of 5 (50ms) to
60,000 (600.00 s).
Note: If your unit has 100 ms ramp feature
enabled, one decimal is implied. The
range is 0.5 s to 6000.0 s.
This value is set with command 16.
02
159
ramp time
remaining
Requests how much ramp time is remaining.
Returning packet contains 2 data bytes
(16 bits), indicating how many 10 ms intervals
remain.
Note: If your unit has 100 ms ramp feature
enabled, the data indicates how many
100 ms intervals remain.
02
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
