request pulse
reverse time
Requests pulse reverse time (read in 0.1 µs
increments); the returning packet contains 1
byte:
• 04 = 0.4 µs
• 05 = 0.5 µs
• 06 = 0.6 µs
• 07 to 49 (follow the established pattern)
• 50 = 5.0 µs
This value is set with command 93.
01
152
request ramp
start set point
percentage
Requests the ramp start set point percentage;
returning packet contains 1 data byte (8-bit)
between 0 and 95 (%).
This value is set with command 32.
01
153
request
joules status
Requests joule mode status; the returning
packet contains 1 byte:
• 0 = Inactive
• Non-zero value = Active
This value is set with command 5.
01
154
request
regulation
mode
Requests the output regulation mode; the
returning packet contains 1 data byte (8-bit
value):
• 6 = Power
•7 = Voltage
•8 = Current
Note: Output power must be off (that is, output
must be deenergized) to switch between
regulation modes.
This value is set with command 3.
01
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
