5702269-C I/O Communication and Control 4-91
Pinnacle™ Plus+ 10 kW
180
request
recipe steps
Requests the number of recipe steps; the
returning packet contains 1 data byte (8-bit
value) indicating the number of steps.
Note: Recall that a value of 0 sent with
command 19 disables the ramping recipe
feature.
This value is set with command 19.
01
181
request
recipe step
ramp time
Requests the amount of ramping time you have
set for a specific ramping recipe step.
Send 1 data byte (8-bit value) indicating the
recipe step.
The returning packet contains 2 data bytes (16-
bit value) indicating the time in seconds. Two
decimal places are implied. For example, a
value of 5 would indicate 0.05 s.
This value is set with command 21.
12
(May return
CSR code 4)
182
request
recipe step
set point and
regulation
mode
Requests the set point level you have set for a
specific ramping recipe step.
Send 1 data byte (8-bit value) indicating the
recipe step. The returning packet contains 3
data bytes:
• First and second bytes = Value of set point
in the mode indicated
• Third byte = Regulation mode
4
6 = Power
4
7 = Voltage
4
8 = Current
This value is set with command 22.
13
(May return
CSR code 4)
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
