4-92 I/O Communication and Control 5702269-C
Advanced Energy
®
183
request
recipe step
run time
or
joule set
point
Requests the run time you set for a specific
recipe step or, if joule recipe is enabled, this
command requests the joule set point.
Send 1 data byte (8-bit value) indicating the
recipe step.
The returning packet contains 2 data bytes
indicating the run time in seconds. Or, if joule
recipe is enabled, returns 4 data bytes (32-bit
value) indicating the joule set point. With
timed recipes, two decimal places are implied.
For example, a value of 5 would indicate 0.05
s.
This value is set with command 23.
12 or 4
(May return
CSR code 4)
184
request out-
of-set point
interval
Requests the amount of time remaining on the
out-of-set point timer before an error condition
occurs; the returning packet contains 2 data
bytes (16-bit value) indicating the interval
value in seconds. One decimal place is implied.
For example a value of 999 would indicate an
interval of 99.9 s.
02
186
request over-
current timer
value
Requests the over-current timer value; the
returning packet contains 2 data bytes (16-bit
value) indicating the value.
This value is set with command 35.
02
187
request out-
of-set point
timer
Requests the out-of-set point timer value; the
returning packet contains 2 data bytes (16-bit
value) indicating the timer value in seconds.
One decimal place is implied. For example, a
value of 999 would indicate a timer value of
99.9 s.
This value is set with command 31.
02
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
