Advanced Energy Pinnacle Plus+ - Page 138

4-94 I/O Communication and Control 5702269-C
Advanced Energy
®
195
request
personality
card
Requests the identity of the unit's personality
cards. The returning packet contains 2 data
bytes:
• First byte = Identity of card in slot 1:
4
0 = Card not present
4
01 or 17 = Dual User port
4
03 or 26= PROFIBUS
4
05 or 21 = Single User port
4
18 or 28 = AE Bus
4
23 or 30 = DeviceNet
• Second byte = Identity of card in slot 2:
4
0 = Card not present
4
03 or 26 = PROFIBUS
4
04 = Host Protocol Translator
4
05 or 21 = Single User port
4
18 or 28 = AE Bus
4
22 or 29 = Master/slave card with AE
Bus
02
196
request
recipe type
Requests the recipe type set with command 33.
Returns 1 data byte.
•1 = Timed
• 2 = Joule continuous
• 3 = Joule discrete
01
197
request flash
configuration
Requests the version level of the unit's flash
memory; returning packet contains 32 data
bytes.
032
198
request s/w
rev level—
mainframe
Requests the revision level of the mainframe
software; the returning packet contains 11
ASCII characters.
011
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
Page 138 of 204
Ex. 1024 Page 138
