5702269-C I/O Communication and Control 4-97
Pinnacle™ Plus+ 10 kW
230
request logic,
panel, or DSP
CRC
Requests the crc of the logic, front panel or
DSP.
The returning packet contains 2 data bytes (16-
bit value).
• To receive the logic CRC, first send
command 24, which calculates the value.
With command 230, send one data byte:
•0 = Logic
•2 = DSP
12
(May return
CSR code 5)
232
request near
end joule
setting
Requests the near end joule setting, set with
command 72.
02
233
request
number of
recipe
repititions
Request the number of recipe repetitions, set
with command 59. Returns 4 data bytes.
• Bytes 1 and 2 = Number of repetitions set
• Bytes 3 and 4 = Current repetition in
process (reports 0 if output is off)
04
251
special
DeviceNet
Requests the full-scale power for DeviceNet
(32-bit value).
04
252
special
DeviceNet
Requests the full-scale current for DeviceNet
(32-bit value).
04
253
special
DeviceNet
DeviceNet poll commands. The returning
packet contains 8 data bytes.
08
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
