4-96 I/O Communication and Control 5702269-C
Advanced Energy
®
220
request
customer
service
statistics
Requests unit statistics; returning packet
contains 4 data bytes (32-bit value).
Send 1 data byte (8-bit value):
• 0 = Total output in kilowatt-hours
• 1 = Total idle time
• 2 = Total run time
• 3 = Total unit on events
• 4 = Total output on events
• 5 = Total over-temperature events
• 6 = Total control circuit faults
• 7 = Total out-of-set point events
• 8 = Total hard bus fault events
• 9 = Total power fluctuation events
• 10 = Unassigned
• 11 = Total Side A inverter low events
• 12 = Total Side B inverter low events
• 13 = Total user interlock open events
• 14 = Total cable interlock open events
• 15 = Total contactor interlock open events
• 18 = Total PROFIBUS fault events
• 19 = Total pre-defined interrupt events
• 20 = Total unassigned interrupt events
• 22 = Total dsp watchdog faults
• 24 = 10 ms bus fault events
14
(May return
CSR code 5)
223
request unit’s
fault status
AE service request 0 4
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
