6-6 Operation 5702269-C
Advanced Energy
®
CABLE RECOMMENDATIONS
Choosing the appropriate cable solution for your Pinnacle Plus+ supply will produce
the best process results. For UHF connectors, RG393 cable is recommended. For two-
pin pluggable connectors, twisted pair cable with an external shield is recommended,
or RG393 for use with PG-11 style strain relief connectors.
In general, the shortest cable will give you the widest process window and the best
results; cables should be no longer than 10 feet (3.05 m). Long cables may cause the
Pinnacle Plus+ supply to turn off because of excessive reflected power.
Never use an output power cable longer than 9.15 m (30 ´) or damage to
your Pinnacle Plus+ unit may result.
