Pinnacle™ Plus+ 10 kW
H004
Continued
on next
page
User Limit
Out of Range
You have attempted to set a
power, voltage or current
limit to a value outside the
allowable range.
Retry setting the limit using
an acceptable value. See the
“Specifications” chapter for
more information.
Timer Out of
Range
You have attempted to set a
timer to a value outside the
allowable range.
Retry setting the timer using
an acceptable value. See the
“I/O Communication and
Control” chapter for more
information.
Arc Count Limit
Out of Range
You have attempted to set
the arc count limit to a value
outside the allowable range.
Retry setting the limit using
an acceptable value. See the
“I/O Communication and
Control” chapter for more
information.
Arc Timer Out
of Range
You have attempted to set
the arc timer to a value
outside its allowable range.
Retry setting the timer using
an acceptable value. See the
“I/O Communication and
Control” chapter for more
information.
Arc Trip Level
Out of Range
You have attempted to set a
trip level to a value outside
the allowable range.
Retry setting the trip level
using an acceptable value.
See the “I/O Communication
and Control” chapter for
more information.
Frequency Out
of Range
You have attempted to set
frequency to a value outside
the allowable range.
Retry setting the frequency
using an acceptable value.
See the “I/O Communication
and Control” chapter for
more information.
Reverse Time
Out of Range
You have attempted to set
reverse time to a value
outside the allowable range.
Retry setting the reverse time
using an acceptable value.
See the “I/O Communication
and Control” chapter for
more information.
Table 7-3. Help Code Troubleshooting Table (Continued)
Help
Code
Number
Help Code
Message
Problem Indicated Suggested Action
