Software 87
4510001 REV B - 220620
Output Refers to Meaning
YB
Tower Light – Green
(RY7)
Output to turn on Relay 7
(for the green Beacon
Light)
: Currently triggered/activated
⬜: Not currently triggered/activated
YC H-Perf Trigger
Output to cycle an optional
Horizontal Perforator
: Currently triggered/activated
⬜: Not currently triggered/activated
YD Print Trigger
Output to operate an
optional Printer
: Currently triggered/activated
⬜: Not currently triggered/activated
Y200 Aux Belt
Output to turn on Relay 10
(for the Auxiliary Belts /
Bottle Holding Devices)
: Currently triggered/activated
⬜: Not currently triggered/activated
