X-ray tube stand tracks wall stand height
To keep constant position of the tube head unit relative to wall stand bucky
while adjusting wall stand height:
1. Set the required position of the X-ray tube stand.
The distance between the X-ray tube head and the table top must not be
less than 15 cm.
Position the X-ray tube head and the table top such that they do not collide
when the X-ray tube stand moves up or down.
2. On the tube head display, press the position tracking button.
WARNING:
Do not use position tracking while the patient is lying on the
table.
Figure 35: Wall stand position tracking disabled and enabled
The button is highlighted.
3. Adjust the wall stand height.
The X-ray tube stand is moving up or down accordingly.
Note: The movement of the X-ray tube is automatically stopped
if the distance between the X-ray tube head and the table top
would become too small (less than 10 cm).
The lock button controls the behaviour of the position tracking after the
exposure is made.
Table 7: Locking the position tracking
Position tracking is not active for the next exposure. It can
be activated again by pressing the position tracking but-
ton.
104 | DR 400 | Software Console and Tube Head Display
3231E EN 20210708 1530
