Manual Collimator Technical Data
Manufacturer Ralco
Via dei Tigli 13/G
20853 Biassono (MB), Italy
Supported type R 221
Maximum radiation leakage 150 kVp – 4 mA
Inherent filtration 2 mm Aluminum equivalent
Added filtration 0mm Al
2mm Al
1mm Al + 0.1mm Cu
1mm Al + 0.2mm Cu
Maximum field Size at SID of 100
cm
48 cm x 48 cm
Dimensions 18.3 cm x 24.1 cm x 16.8 cm (WxDxH)
Weight 7.7 kg
244 | DR 400 | Product Information
3231E EN 20210708 1530
