Additional Labeling of the radiographic wall stand
(Sample of subtype 5522/100)
Type label on the lower right hand side of
the radiographic wall stand.
This mark indicates that the equipment has
a Type B applied part
Functional earth
The bucky can be tilted to horizontal posi-
tion. Do not use the bucky as a seat.
A pinch point label is located on top of the
tilting extension.
Related Links
Radiographic Wall Stand Technical Data on page 236
DR 400 | Introduction to DR 400 | 49
3231E EN 20210708 1530
