Oblique Exposures
1. Position the patient on the radiographic table.
2. Move the X-ray tube stand out of the coupling range of the bucky.
3. Position the bucky under the patient.
4. Set the required angle of the X-ray tube.
5. Adjust the position of the X-ray tube stand to align the X-ray exposure field
to the center of the bucky using the collimator light and the bucky markers
for orientation.
Figure 29: Oblique Exposures
DR 400 | Basic Workflow | 91
3231E EN 20210708 1530
