Radiographic Wall Stand Technical Data
Manufacturer Agfa NV
Septestraat 27
2640 Mortsel, Belgium
Type
WS-Manual-001
5522/100
WS-Manual-T-001 5522/200
WS-Manual-002
5522/300
WS-Manual-T-002 5522/400
Dimensions
Height 2245 mm
Width 610 mm (only front panel)
715 mm (with tilting handles)
825 mm (with patient hand grips)
Depth 380 mm (vertical wall stand)
640 mm (tilting wall stand)
730 mm (vertical wall stand with spacer)
990 mm (tilting wall stand with spacer)
Height of detector center 33.5 to 185 cm
Angle of the detector -20° to +90°
Typical SID range
(*)
100 cm to 280 cm (decided during installa-
tion)
Distance between front pan-
el and detector
(*)
48 mm
Front panel attenuation
equivalent mm Aluminum
≤ 0.7
According to
236 | DR 400 | Product Information
3231E EN 20210708 1530
