Grid Status
Table 13: Grid status - automatically detected
(no icon) No grid is required.
The correct grid type is inserted.
The correct grid type is not inserted.
A grid is inserted, but no grid is required.
The SID does not correspond to the inserted grid.
The grid is inserted wrongly.
The focal distance of the grid that is detected in the bucky, is displayed inside
the icon.
Table 14: Grid status - not automatically detected
(no icon) No grid is required.
A grid is required.
112 | DR 400 | Software Console and Tube Head Display
