System messages
System messages are displayed at the bottom of the software console.
The color of the message indicates the importance:
Blue Information
Yellow Warning
Orange Error
Messages that require feedback from the user contain a button that can be
pressed.
Figure 41: Error message requiring user feedback
More than one message can be active. The number of active messages and the
type of messages is indicated on the navigation button.
Figure 42: Icon indicating that messages are waiting
DR 400 | Software Console and Tube Head Display | 127
3231E EN 20210708 1530
