AGFA DR 400 - Cables, Transducers and Accessories

Cables, transducers and accessories
Cables, transducers and accessories which were tested and found to comply
with the collateral standard IEC60601-1-2 (EMC):
CAUTION:
Use of accessories, transducers and cables other than those
specified or provided by the manufacturer of this equipment
could result in increased electromagnetic emissions or
decreased electromagnetic immunity of this equipment and
result in improper operation.
from;
to
type;
maximum length
remark
Transfer point table;
transfer point wall stand
10 x AWG21 (0.5 mm
2
)
;
20 m
unshielded
control room (light push button);
table input terminal
2 x AWG21 (0.5 mm
2
);
15 m
not delivered
with the sys-
tem
control room (lamp red);
table input terminal
2 x AWG18 (1.0 mm
2
);
15 m
not delivered
with the sys-
tem
control room (lamp yellow);
table input terminal
2 x AWG18 (1.0 mm
2
);
15 m
not delivered
with the sys-
tem
control room (door contact);
table input terminal
2 x AWG18 (1.0 mm
2
);
15 m
not delivered
with the sys-
tem
control room (Com A);
table input terminal
9 pin sub D;
20 m
shielded
control room (Com B);
table input terminal
Standard RS-232 cable (9
pin sub D);
20 m
shielded
control room (ground);
table input terminal
1 x AWG8 (10 mm
2
)
;
15 m
mandatory
