AGFA DR 400 - Page 263

from;
to
type;
maximum length
remark
Table output terminal (x8 24V,
light push button, double expo-
sure protection);
wall stand input terminal
10 x AWG21 (0.5 mm
2
);
20 m
mandatory
table output terminal (230 V);
wall stand input terminal
3 x AWG18 (1.0 mm
2
);
20 m
mandatory
table output terminal (AEC);
wall stand input terminal
CAT 5e (SF/UTP);
20 m
shielded
mandatory
table output terminal (ground);
wall stand input terminal
1 x AWG8 (10 mm
2
);
20 m
mandatory
Optional
control room (DR Generator
Sync Box 1);
table input terminal (Sync 01)
9 pin sub D (Pin 9 is not
connected);
20 m
unshielded
control room (DR Generator
Sync Box 2);
table input terminal (Sync 02)
9 pin sub D (Pin 9 is not
connected);
20 m
unshielded
control room (DR Generator
Sync Box 1);
wall stand input terminal (Sync
03)
9 pin sub D (Pin 9 is not
connected);
20 m
unshielded
control room (DR Generator
Sync Box 2);
wall stand input terminal (Sync
04)
9 pin sub D (Pin 9 is not
connected);
20 m
unshielded
DX-D Fixed DR Detector or DR
Detector I/O box;
NX workstation
CAT 6 SF/UTP;
40 m
shielded (no
connectors
allowed)
table output terminal Aux.;
control room NX Workstation
Cat 5e;
15 m
shielded
table output terminal; 01090350F;
unshielded,
optional
