Pixel Matrix Pixium RAD
4343 C
Pixium RAD
4343 G
Pixium RAD
4343 C-E
Pixium RAD
4343 G-E
Pixel size 148 µm (H,V)
Pixel matrix 2880(H) x 2880(V)
Active pixel
matrix
2869(H) x 2874(V) 2860(H) x 2874(V)
Fill factor 100 %
Detector type Amorphous Silicon
Active area
size
426.6 mm (H) x 425.4 mm
(V)
426.24 mm (H) x 426.24 mm
(V)
Fixed DR Detector environmental conditions
Pixium RAD 4343 C
Environmental Conditions (during normal operation)
Temperature (ambient) between 15° and 35° Celsius
Humidity
Atmospheric pressure
Maximum altitude
Refer to environmental conditions of the X-ray sys-
tem
minimum maximum
Distance to calibration temperature -6 °C +6 °C
Distance to calibration pressure -100 mbar +100 mbar
Pixium RAD 4343 C-E
Environmental Conditions (during normal operation)
Temperature (ambient) between 15° and 35° Celsius
Humidity
Atmospheric pressure
Maximum altitude
Refer to environmental conditions of the X-ray sys-
tem
