Detectors
Agilent 6890 Gas Chromatograph Service Manual
Flame Ionization Detector (FID) 310
Theory of operation
Figure 310-3 Manual detector flow
On/off
solenoid
valves
Restrictors
Ven t
Pressure
regulator
Aip in
H
2
in
Makeup in
