9 of 24
Jun 2001
Detectors
Agilent 6890 Gas Chromatograph Service Manual
Electron Capture Detector (ECD) 340
Replacement procedures
Figure 340-8 Removing the heater/sensor
4. Slide the heater and sensor out of the heated blocks.
Heater/sensor assembly
Heated blocks
