5 of 36
Jun 2001
Detectors
Agilent 6890 Gas Chromatograph Service Manual
Flame Photometric Detector (FPD) 350
Replacement procedures
Figure 350-2 Replacing the FPD assemblies
6. Trace the ignitor cable from the FPD to its source on the detector board,
and disconnect it. Note the locations of the signal and high voltage cables,
then remove them from the board.
Typ e 1 ma nifol d a ssem bly
Detector assembly
Valve bracket assembly
Detector PCB
