5 of 20
Jun 2001
Mainframe
Agilent 6890 Gas Chromatograph Service Manual
Covers and Fans 410
If your detector cover rests on a post on the electronic cover
1. Raise the detector cover to the straight-up position.
2. Tilt the cover to the left to remove it.
Figure 410-5 Removing the detector cover
Top co ver
Electronics cover
