Agilent Technologies 6890 Series Service Manual

5 of 14
Jun 2001
Cabling Configuration and Electronics
Agilent 6890 Gas Chromatograph Service Manual
Cabling Diagrams, 6890A and 6890 Plus 1010
6890 GC 3396B/C INET Integrator GC Automatic Liquid Sampler Modem
6890 GC
3396B/C INET Integrator
GC Automatic Liquid Sampler
Modem
Figure 1010-5
Number Part no. and description
1 G1530-60600, 2-m RS-232 cable, 9-pin female/9-pin female
2 G1530-60930, 2-m APG remote cable, 9-pin male/9-pin male
3 Two 82167-60003, 5-m INET cables
4 G1530-61120, Modem cable, 9-pin female/9-pin male
OR 24540-80012 (also 24542M), Modem cable 9-pin female/25-pin
male
6890 GC ALS
1 RS-232
2 APG remote
Modem
4 Modem
INET Integrator
The 7683 ALS
controller is internal to
the 6890 Plus GC.
The G2613A injector
and G2614A tray
plug into the GC.
3 INET
