1015 Cabling Diagrams, 6890N
6890N GC GC ChemStation/Cerity GC Automatic Liquid Sampler
2 of 14
Jun 2001
Cabling Configuration and Electronics
Agilent 6890 Gas Chromatograph Service Manual
6890N GC
GC ChemStation/Cerity
GC Automatic Liquid Sampler
Figure 1015-2 GC-networked-GC ChemStation/Cerity-GC ALS
Number Part no. and description
1 G1530-61485, Cable, 100 Base T-LAN
2 G1530-61120, RS-232/modem cable or 24540-80012,
RS-232/modem cable
6890N GC
(with 7683 ALS
if used)*
Networked
GC ChemStation/Cerity
1 LAN cable
* The 7683 controller is internal to the 6890N GC. The G2613A Injector and the G2614A
tray plug directly into the GC.
Hub
Modem
2 RS -232
