Agilent Technologies 6890 Series Service Manual

1015 Cabling Diagrams, 6890N
6890N GC 7694 Headspace Sampler GC ChemStation
8 of 14
Jun 2001
Cabling Configuration and Electronics
Agilent 6890 Gas Chromatograph Service Manual
6890N GC
7694 Headspace Sampler
GC ChemStation
Figure 1015-7
Number Part no. and description
1 G1290-60575, APG remote cable, 3-pin male/4-pin male
2 G1530-61485, Cable, 100 Base T-LAN
3 G1290-60650, RS-232 cable, 9-pin female/9-pin female
6890N GC
7694 HS
1 APG remote
2 LAN
GC ChemStation
3 RS-232
