Cabling Configuration and Electronics
Agilent 6890 Gas Chromatograph Service Manual
Cable Electronics 1020
Modem/RS-232C
Modem/RS-232C
Cable pinouts, 6890 GC to Computer via RS-232, 9-pin/9-pin
Connector 1 — 9 pin (female) Connector 2 — 9 pin (female)
1— DCD
6— DSR
4 — DTR
2 — Rx 3 — Tx
3 — Tx 2 — Rx
4 — DTR 6 — DSR
1 — DCD
5 — Ground 5 — Ground
7 — RTS 8 — CTS
8 — CTS 7 — RTS
9 — RI
1
5
6
9
9
6
5
1
G1530-60600
Part no. G1530-60600
5
1
1
5
6
9
1
2
