1310 Inlets
Volatiles interface calibrated manifold assembly
30 of 36
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Volatiles interface calibrated manifold assembly
(part no. G2319-60500)
For diagram of screw and O–ring placement in pneumatic modules see
Figure 1310-7 on page 15 of this section.
Description Part no. Qty.
1. Male connectors 1/8-inch Swagelok G1543-80030 2
2. Screw, M4 × 45 mm, Torx T-20 0515-2484 1
3. Inlet supply fitting G1543-20510 1
4. Screw, M3 × 20 mm, Torx T-10 0515-1319 8
5. O-rings, under connectors and fitting (12/pkg) 5180-4182 1
