1320 Detectors
Nitrogen Phosphorus Detector manifold assembly
12 of 30
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Nitrogen Phosphorus Detector manifold assembly
Description Part no. Qty
Type 1 Manifold
1. Non-EPC 2 way valve G1531-60530 3
2. O-rings HPM8 (Order no. 5180-4181, 12/pkg) 0905-1039 9
3. Screw, M4 x 6 mm, Torx, T20 0515-2832 1
4. EPC control module assembly G1534-60520 1
5. Non-EPC control module G1534-60500 1
6. Screw, M3 × 25 mm, Torx T10 0515-0683 6
7. Screw, M3 × 8 mm, Torx, T10 0515-0655 2
8. Make-up Gas, manual forward pressure regulator
assembly
G1531-60570 1
8A. Pressure regulator, 0 to 100 psi G1531-60630 1
8B. NPD manifold regulator brazement G1531-80520 1
8C. Supply gas jumper brazement G1531-80550 1
Type 2 Manifold
9. Replacement EPC manifold assembly G1534-60720 1
