1320 Detectors
Thermal Conductivity Detector manifold assembly
16 of 30
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Thermal Conductivity Detector manifold assembly
Description Part no. Qty
Type 1 Manifold
1. Non-EPC detector on-off valve G1531-60530 2
2. O-rings HPM8 Order no. 5180-4181, 12/pkg) 0905-1039 9
3. Screw, M4 × 6 mm, Torx, T20 0515-2832 2
4. EPC control module assembly G1532-60720 1
5. Non-EPC control module assembly G1532-60500 1
6. Screw, M3 × 8 mm, Torx T10 0515-0655 2
7. Make-up gas, manual forward G1532-60530 1
pressure regulator assembly
7A. Pressure regulator, 0 to 100 psi G1531-60630 1
7B. TCD Manifold regulator brazement G1532-80530 1
8. TCD 3-Way switching valve G1532-60570 1
Type 2 Manifold
9. Replacement EPC manifold assembly (replaces either
type)
G1532-60720 1
