1320 Detectors
Flame Photometric Detector (FPD)
22 of 30
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Flame Photometric Detector (FPD)
Description Part no. Qty.
1. Exit tube assembly–A1 19256-20700 1
1A. Exit tube assembly–SST 19256-20705 1
2. Nut, brass, 1/4-inch 0100-0056 1
3. Ferrule, Vespel, 1/4-inch ID (order no. 5080-8774) 0100-1061 1
4. Weldment, block 19256-80560 1
5. O-ring (Kalrez) ignitor 0905-1102 1
6. Spacer, ignitor 19256-20590 1
7. Glow plug 0854-0141 1
8. Ignitor cable assembly G1535-60600 –
9. Gasket, heat shield 19256-80040 1
10. Window, first heat shield 19256-80030 1
11. Disk, heat shield 19256-20580 1
12. Coupling, stainless steel 19256-20550 1
13. Lockwasher (4 required) 2190-0108 4
14. Screw, M3 × 12 (4 required) 0515-0911 4
15. Clamp 19256-00090 1
16. O-ring, silicone, 0.926-inch ID (orange) 0905-0955 1
17. Window, second heat shield 19256-80060 1
18. O-ring, silicone, 1.05-inch ID (orange) 0905-1104 1
19. Flange adapter 19256-20510 1
20. Flange ring 19256-00200 1
21. Screw, M3 × 25 (4 required) 0515-0065 4
22. O-ring, Viton, 1.239-inch ID (brown) 0905-1100 1
