1320 Detectors
Flame Photometric Detector covers, manifolds, and electronics
28 of 30
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Flame Photometric Detector covers, manifolds, and electronics
Description Part no. Qty.
Covers and electronics
1. Flame photometric detector assembly 1
Single wavelength FPD G1535-60555
Dual wavelength FPD (not shown) G1535-60565
2. Detector top cover, single FPD (not shown) G1535-80550 1
2A. Detector top cover, dual FPDs G1535-80560 1
3. Electronics cover pan G1535-00120 1
4. Electronics top cover G1535-80540 1
Cover assembly (6890 GC) (not shown) G1535-80520 1
5. Actuator solenoid bracket (optional) G1580-00070 –
6. Printed circuit board G1535-60010 1
Spring (not shown) 1460-1160 1
Manifolds
7. Replacement FPD manifold G1535-60720
8. Replacement EPC FPD manifold, Type 2, Kit (replaces
either type)
G1535-60720
