1330 Covers
Plastic covers
4 of 8
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Plastic covers
See also Figure 1320-14 for ordering covers for GCs with 1 (or 2) flame
photometric detector(s).
Description Part no. Qty.
1. Automated Liquid Sampler tray bracket* (optional) 18597-60875 1
2. Injection port fan cover G1530-40200 1
3. Injection port top cover G1530-40070 1
4. Pneumatics cover G1530-40040 1
5. Detector top cover** G1530-40130 1
6. Electronics top cover** G1530-40125 1
7. Left side cover G1530-40050 1
8. Screw, M4 × 12 mm, Torx, T-10 1390-1023 10
9. Electronics side cover G1530-40115 1
10. 3-inch hole plug 6960-0162 2
11. 1-inch hole plug 6960-0163 2
12. 1 1/2-inch hole plug 6960-0164 1
13. Circular plug label G1530-90870 4
14. Oval plug label G1530-90880 2
NS. Injector mounting post, 7683 07673-21140 1
NS. Injector mounting post, G2613A G2613-20500 1
* Note: If your GC uses a metal hinge for the detector top cover, you must replace items
5 and 6 together. Order kit number G1530-67075. For more information, see Replacing
the detector top cover.
* Bracket used for 18596 A/B tray only. Not used for G2614 tray on the 6890 Plus GC.
