Valve actuator assembly (1 of 2)
6 of 14
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Valve actuator assembly (1 of 2)
Description Part no. Qty.
1. Valve actuator assembly G1580-60660 1
2. Modified screw 19325-80030 2
3. Quick-release pin 1480-0632 1
4. 1/8-inch Hose fitting, 10-32 × 1/16-inch ID, hose barb 0100-1205 2
5. Teflon tubing 1/8-inch od
(order by the inch; 42 inches for each actuator)
0890-0746
6. 36° Actuator limiter 18900-21000 1
7. End cap 19325-20680 1
8. Elbow fitting, 10 to 32 0100-1220 1
9. Coupler/Shaft assembly G1580-60640 1
NS Hex key, 3 mm (not shown) 8710-0911 —
