1360 Electrical
Main circuit board, 6890A and 6890 Plus
6 of 16
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Main circuit board, 6890A and 6890 Plus
Only ROM sockets 0 and 1 are used.
• ROM G1530-80906 Socket 0
• ROM G1530-80926 Socket 1
Description Part no. Qty.
1. Main board assembly G1530-60011 1
2. Hex screw, self-tapping 0624-0665 3
3. Grounding screw, M4 × 25 mm, Torx, T-20 0515-2712 2
4. Glass fuse, type F, 8A/250V 2110-0036 4
5. Battery, 3V 1420-0523 1
6. ROM kit, rev. A.03.08 G1530-61706 1
7. ROM puller (not shown) 8710-2303 –
