9 of 16
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Electrical 1360
Modular input/output (MIO) components (6890A and 6890 Plus)
Modular input/output (MIO) components (6890A and 6890 Plus)
INET components
LAN components
The JetDirect cards (LAN card assy), part no. J2552-69013, were modified to add
additional capabilities in early 1998. New cards should have the new firmware;
older cards should not be used. For a first-time installation into a 6890 GC,
purchase G2335A to receive all necessary mounting hardware and GC firmware.
The G1530A option #500 is the factory-installed version.
Description Part no. Qty.
1. INET MIO card assy G1553-60015 1
2. MIO support bracket G1530-00320 1
3. MIO connector assy G1553-60100 1
4. Support bracket standoff, M3 male/female G1530-20570 1
5. Screw, Torx T-10, M3 × 6 mm 0515-0680 1
6. Screw, Torx T-20, M4 × 12 mm 0515-2496 3
7. 5 Meter HP-IL cable (not shown) 82167-60003 1
8. INET cover plate G1530-00610 1
Description Part no. Qty.
1A. LAN card assy (J2552B) J2552-69013 1
2. MIO support bracket G1550-00320 1
3. MIO connector assy G1553-60100 1
4. Support bracket standoff, M3 male/female G1530-20570 1
5. Screw, Torx T-10, M3 × 6 mm 0515-0680 1
6. Screw, Torx T-20, M4 × 12 mm 0515-2496 3
7A. 8 Meter thin LAN cable (not shown) 92227-60004 1
8. Loopback connector (not shown) 92227Q 1
9. Replacement LAN card (not shown) J2552-69013 –
10. LAN cable, black crossover PC to 1 GC (not for use on hub)
(Not shown)
5183-4649
