The Keypad
User Information 49
The Keypad
Table 2 below lists all the keys on the Headspace Sampler, and
summarizes their functions. See Keys and Their Functions on
page 50 for details.
Figure 13 shows the layout of the keypad.
Tabl e 2 Quick reference of keys and functions
Key Definition/Function
Start/Stop Starts, Stops and/or resets a run
Active Method Displays a menu for editing method parameters
Menu Displays the main menu for access to advanced functions
and loading, storing, and chaining methods
Tray Advance Moves tray one position
Cursor keys Navigates through menu options
Clear Cancels a keyboard entry. Displays menu top level
Enter Adds keyboard entry to current method or executes
highlighted selection
Figure 13 The keypad
medium_standard.book Page 49 Tuesday, February 17, 2004 10:14 AM
