132 User Information
Maintaining the Instrument
Changing the Sampling Probe
Follow the steps in Table 11 to change the sampling probe.
Tabl e 11 Changing the sampling probe
Step Action Notes
1 Remove the loop cover. Follow the
steps on page 130.
2 Remove the heater block covering
the sampling probe.
a Loosen the Phillips screw shown
below.
b Lift out the heater block.
Screw
Heater block
