[SENSe:]CURRent:AC:BANDwidth
CONFigure:DIODe
Sets all measurement parameters and trigger parameters to their default values for diode tests.
Parameter Typical Return
(none) (none)
Configure, make, and read a default diode measurement:
CONF:DIOD
READ?
Typical Response: +1.32130000E-01
l The range and resolution are fixed for diode tests: the range is 1 VDC (with a 1 mA current source output).
l The voltage is displayed on the front panel if it is between 0 and 5.05 V. The instrument beeps when the signal
transitions into the range between 0.3 and 0.8 V (unless beeper is disabled). If the signal exceeds 5.05 V, the front
panel shows "OPEN", and the value returned from SCPI is 9.9E37.
l The FETCh?, READ?, and MEASure:DIODe? queries return the measured voltage, regardless of its value.
l Use READ? or INITiate to start the measurement.
Agilent Truevolt Series DMM Operating and Service Guide 141
