[SENSe:]{FREQuency|PERiod}:VOLTage:RANGe{<range>|MIN|MAX|DEF}
[SENSe:]{FREQuency|PERiod}:VOLTage:RANGe? [{MIN|MAX|DEF}]
Selects a fixed voltage range for frequency and period measurements.
This parameter is shared between frequency and period measurements. Setting or querying the
parameter with the FREQuency version of this command is identical to setting or querying it with the
PERiod version.
The maximum range parameter (MAX) is 1000 V. However, the SAFETY LIMIT on the front
and rear HI/LO input terminals is 750 VAC (rms). The rms voltage is waveform dependent.
A sine wave is limited to 750 VAC (rms), but a 1000 Vpk square wave is safe. Connection
to AC mains power is further limited to CAT II (300 V). See Safety and Regulatory
Information for more information on the safety features and the safe operation of this
instrument.
Parameter Typical Return
{100 mV|1 V|10 V|100 V|1000 V}, default 10 V +1.04530000E+03
Configures frequency measurements using the 10 VAC range. Make and read two measurements:
CONF:FREQ
FREQ:VOLT:RANG 10
SAMP:COUN 2
READ?
l Selecting a fixed range ([SENSe:]<function>:RANGe) disables autoranging.
l If the input voltage is too large for the selected voltage range (manual ranging), the instrument displays the word
Overload on the front panel and returns "9.9E37" from the remote interface. Autoranging can be enabled for the
input voltage.
l This parameter is set to its default value after a Factory Reset (*RST) or Instrument Preset (SYSTem:PRESet).
202 Agilent Truevolt Series DMM Operating and Service Guide
