Pin Location Detail

U1004 pin 3

5 V ± 5%

U111 (next to shield screw)

pin 7: 16.8 V ± 5%

pin 4: -16.4 V ± 5%

292 Agilent Truevolt Series DMM Operating and Service Guide
