Safety Information
General
Do not use this product in any manner not specified by the manufacturer. The protective features of this product may
be impaired if it is used in a manner not specified in the operation instructions. Do not install substitute parts or perform
any unauthorized modification to the product. Return the product to an Agilent Technologies Sales and Service Office
for service and repair to ensure that safety features are maintained.
Product Grounding
The instrument is a Class 1 product and is provided with a grounding-type power cord set.
The instrument chassis and cover are connected to the instrument electrical ground to
minimize shock hazard. The ground pin of the cord set plug must be firmly connected to the
electrical ground (safety ground) terminal at the power outlet. Any interruption of the
protective earth (grounding) conductor or disconnection of the protective earth terminal
will cause a potential shock hazard that could result in personal injury or death.
Cleaning
To prevent electrical shock, disconnect the instrument from AC mains power and disconnect
all test leads before cleaning. Clean the outside of the instrument using a soft, lint-free,
cloth slightly dampened with water.Do not use detergent or solvents.Do not attempt to clean
internally.If needed, contact an Agilent Technologies Sales and Service office to arrange for
proper cleaning to ensure that safety features and performance are maintained.
AC Power Cord
Removal of the AC power cord is the disconnect method to remove power from the
instrument. Be sure to allow for adequate access to the power cord to permit disconnection
from AC power. Use only the Agilent specified power cord for the country of use or one with
equivalent ratings.
Do Not Remove Instrument Cover
Only qualified, service-trained personnel should remove the cover from the instrument.
Service: Unplug instrument from wall outlet, remove power cord, and remove all probes
from all terminals before servicing.
AC Mains Power Line Fuse
For continued protection against fire, replace the line fuse only with fuses of the specified
type and rating. The instrument must be disconnected from AC mains power, and all
measurement terminals must be disconnected before changing the fuse.
Current Measurement Protection Fuse
For continued protection against fire, replace current-protection fuses only with fuses of the
specified type and rating. The instrument must be disconnected from AC mains power, and
all measurement terminals must be disconnected before changing the fuse.
Front/Rear Switch
Do not change the position of the Front/Rear switch on the front panel while signals are
present on either the front or rear set of terminals. The switch is not intended as an active
multiplexer. Switching while current or high voltage is present may cause instrument
damage and lead to the risk of electric shock.
Do Not Operate in an Explosive Atmosphere
This instrument is not designed to be operated in an explosive environment. The instrument
enclosure complies with the IP 20 rating.
Agilent Truevolt Series DMM Operating and Service Guide 5
