Chapter 13: Using the Effects
PING PONG DELAY
This delay effect pans the effect sound left and right.
1
2
3
4
5
6
Parameter Setting range Function
1 Delay *1 1ms – 1500ms Adjusts the delay time.
2 Fdback *2 0 – 127 Adjusts the amount of delay feedback.
3 HFdamp *3 20Hz – 20kHz Sets a frequency at which the higher range of the feedback sound is cut.
4 Width *6 0 – 127 Adjusts the panning width.
5 Balance +50 – 0 – –50 Adjusts the balance between the effect sound and dry sound. (Effect
sound only at a value of +50)
6 Effect ON/OFF Switches the effect sound output on and off.
PANNING DELAY
This delay effect pans the delay sound left, center, then right (LCR), or right, center, then left (RCL).
1
2
3
4
5
6
7
Parameter Setting range Function
1 Delay *1 1ms – 1500ms Adjusts the delay time.
2 Fdback *2 0 – 127 Adjusts the amount of delay feedback.
3 HFdamp *3 20Hz – 20kHz Sets a frequency at which the higher range of the feedback sound is cut.
4 Mode *4 LCR/RCL Sets the panning effect.
5 Width *6 0 – 127 Adjusts the panning width.
6 Balance +50 – 0 – –50 Adjusts the balance between the effect sound and dry sound. (Effect
sound only at a value of +50)
7 Effect ON/OFF Switches the effect sound output on and off.
